• The iFlight BOB57 is a long-range HD drone that was designed in collaboration with pilot & videographer Ellis van Jason. The team crafted this cinematic 6-inch drone that ensures agility and flight time while combining the advantages of both 5-inch and 7-inch drones for both cinematic and freestyle flights.


Highlights

• Hybrid motor design optimized for  that can be used with both bi-blade and tri-blade 6" propellers

• High-end GPS is used to minimize the risk of failure during proximity flights

• Long backbone with enough space up to fit 3000mAh 6S batteries

• Solid antenna mount for less ocillations when using long antennas

• Gladiator shell protects from dust and water droplets

• ESCs with built-in spike absorber for more reliability

• Built in BEC to directly power a GoPro camera

• 9-minute flight time with 3000mAh 6S Lipo

• Front-mounting XT-60

Specifications

• Product Name: BOB57 O4 6S HD BNF

• FC: BLITZ F722

• ESC: BLITZ E55 55A 4-IN-1 ESC

• Video Transmission: DJI O4 Air Unit Pro

• Frame: 280mm wheelbase

• Motor: XING2 2506 1500KV motors

• Prop: GEMFAN 6032-3 propellers

• Weight: 570±5g

• Takeoff Weight: Approx.795±5g (With 6S 1480mAh)

• Dimensions (L×W×H): 226×166×34 mm

• Max Speed: 180 km/h (Manual Mode)

• Maximum Takeoff Altitude: 7000 m

• Max Hover Time: Approx. 8.5 mins (With 6S 1400 no load.)

• Max Wind Speed Resistance: Level 7

• Operating Temperature Range: -10° to 40° C

• Antennas: 2 Antenna

• GNSS: GPS+SBAS+Galileo+QZSS+Glonass

Video Transmission

• Product Name: DJI O4 Air Unit Pro

• Image Sensor: 1/1.3-inch

• Lens: FOV: 155°

• ISO: 100-25600

• Video Resolution: 1080p/100fps H.265

• Video Format: MP4, Max Video Bitrate: 130Mbps

• Color Mode: Normal Mode/D-Log M

• Stabilization: RockSteady 3.0+ ; Stabilization function off (When RockSteady is enabled, the shooting angle only supports standard.)

• Live View Quality: 1080P@100fps

• Operating Frequency: 5.170-5.250 GHz  & 5.725-5.850 GHz

• Transmitter Power (EIRP): 5.1GHz＜23dBm(CE)/5.8GHz＜33dBm(FCC)/＜14dBm(CE)/＜30dBm(SRRC))

• Max Video Transmission Range: With DJI Goggles 3/DJI Goggles N3: 15 km (FCC), 8 km (CE), 8 km (SRRC)

• Communication Bandwidth: Max 60 MHz

• Antenna: Dual antennas

• Built-in Storage: 4GB

• Supported SD cards: microSD (up to 512GB)

• Operating Temperature: -10° to 40° C

• Weight: Air Unit (camera module included): Approx. 32 g

• Dimensions: Transmission Module: 33.5×33.5×13 mm (L×W×H)

Package included

• 1 x BOB57 6S O4 HD BNF

• 2 x Antennas

• 1 x Battery pads

• 2 x Prop(Pairs)
